Load Measurement

Specifications and Features

Purpose/Function

Inspection/Measurement Drive/Actuation

No load other than when measuring When pressing a bushing into a nylon gear, measure the load applied to the bushing. The measuring rod is pushed to the transfer surface by a cam mechanism only during load measurement. Environment/Operability: No protrusions on the transfer line, and the entire unit is installed below the transfer surface to save space.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Set Screw	E-GMSSU6-10	Screw nominal (M): 6 Length L(mm): 10 Material: Stainless steel RoHS10 compliant	1	MYR 0.30/Unit
②	Set Screw	E-GMSSU5-6	Screw nominal (M): 5 Length L(mm): 6 Material: Stainless steel RoHS10 compliant	1	MYR 0.25/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Hex Socket Set Screws - Cup Point, Stainless Steel[RoHS Comliant] MYR 0.22 /Unit Shipping: 4 Days

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
