Low Pressure Fittings/Plug
Part Number
Configured Part Number is shown.
| Type | [ M ] Material | [ S ] Surface Treatment |
| SGPPP | FCMB270 | Hot Zinc Plating |
| SUPPP | SUS304 | - |
Specifications
| Part Number | - | L |
| SGPPT8A SGPNPR8A | - | 75 |
Part Number
CAD Data download and 3D preview are not available because the part number has not yet been determined.
- *In order to open the CAD Data download and 3D preview screen, the part number must be fixed.
- Please confirm the part number from "Specification / Dimension"on the left side, and then perform the CAD Data Download / 3D Preview operation.
| Part Number |
|---|
| SGCPP15A |
| SGPPP15A |
| SUCPP15A |
| SUPPP15A |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | RoHS | Material | Nominal of Thread Rc (PT) or T or T1 or Q or Q1 | Applicable Fluid | Surface Treatment | Seal Coating |
|---|---|---|---|---|---|---|---|---|---|---|
MYR 15.30 | 1 Piece(s) | Available | 2 Day(s) or more | - | [Steel] FCMB270 | 1/2B(15A) | Pulsating Water, Static Flow Water / Air / Gas / Oil | Hot Zinc Plating | - | |
MYR 4.71 | 1 Piece(s) | Available | 1 Day(s) | - | 00163 / [Steel] FCMB270 | 1/2B(15A) | Pulsating Water, Static Flow Water / Air / vapor / Gas / Oil | Trivalent Chromate / Hot Zinc Plating | - | |
MYR 16.48 | 1 Piece(s) | Available | 1 Day(s) | - | [Stainless Steel] SCS13A | 1/2B(15A) | - | No | - | |
MYR 11.17 | 1 Piece(s) | Available | 1 Day(s) | - | [Stainless Steel] SCS13A | 1/2B(15A) | - | No | - |
Loading...
More Information
Operating Conditions of Joints| Fluid State | Max. Operating Pressure MPa (kgf/cm2) |
| Steam, Air, Gas, Oil: Up to 300°C | 1.0 (10.2) |
| Steam, Air, Oil, Pulsating Water: Up to 200°C | 1.4 (14.3) |
| Static Flow Water: Up to 120°C | 2.0 (20.4) |
(Except for transitional change)
*Static Flow Water is a non-pulsating stream of water.
Basic Information
| Type | Fitting | Connection Type | Screws | Connecting Shape | Plug |
|---|---|---|---|---|---|
| Connecting Thread Type (1) | R | Max. Operating Pressure(MPa) | 2 |
Specification/Dimensions
-
Material
- Stainless Steel
- Steel
- 00163
- Stainless Steel
-
Applicable Fluid
- Pulsating Water, Static Flow Water
- Air
- vapor
- Gas
- Oil
-
Surface Treatment
- No
- Trivalent Chromate
- Hot Zinc Plating
-
Seal Coating
- Not Provided
- Provided
-
type
- SGCPP
- SGPPP
- SUCPP
- SUPPP
-
Nominal of Thread Rc (PT) or T or T1 or Q or Q1
- 1/8B(6A)
- 1/4B(8A)
- 3/8B(10A)
- 1/2B(15A)
- 3/4B(20A)
- 1B(25A)
- 2B(50A)
-
CAD
- 2D
- 3D
Days to Ship
-
- All
- 1 Day(s) or Less
- 2 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
