Casters for Pipe Frames- Standard Type/Plastic Joint Insert Type
Part Number
Configured Part Number is shown.
Part Number
CAD Data download and 3D preview are not available because the part number has not yet been determined.
- *In order to open the CAD Data download and 3D preview screen, the part number must be fixed.
- Please confirm the part number from "Specification / Dimension"on the left side, and then perform the CAD Data Download / 3D Preview operation.
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | RoHS | Caster Type_2 | Max. Load (N) | Wheel Dia. D (mm) | Wheel Material |
|---|---|---|---|---|---|---|---|---|---|
MYR 31.51 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 392 | 50 | C (Iron: FC20 Bright Chromate) | |
MYR 55.54 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 392 | 50 | M (MC Nylon) | |
MYR 15.48 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 392 | 50 | N (Nylon) | |
MYR 15.48 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 343 | 50 | R (Synthetic Rubber) | |
MYR 22.96 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 343 | 50 | T (Conductive Rubber) | |
MYR 18.69 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 392 | 50 | U (Urethane) | |
MYR 59.28 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 784 | 75 | C (Iron: FC20 Bright Chromate) | |
MYR 108.95 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 784 | 75 | M (MC Nylon) | |
MYR 36.32 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 784 | 75 | N (Nylon) | |
MYR 36.32 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 588 | 75 | R (Synthetic Rubber) | |
MYR 59.81 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 588 | 75 | T (Conductive Rubber) | |
MYR 52.33 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 686 | 75 | U (Urethane) | |
MYR 63.55 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 588 | 100 | R (Synthetic Rubber) | |
MYR 72.10 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 490 | 100 | T (Conductive Rubber) | |
MYR 68.89 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel | 588 | 100 | U (Urethane) | |
MYR 34.71 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 392 | 50 | C (Iron: FC20 Bright Chromate) | |
MYR 58.74 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 392 | 50 | M (MC Nylon) | |
MYR 18.16 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 392 | 50 | N (Nylon) | |
MYR 18.16 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 343 | 50 | R (Synthetic Rubber) | |
MYR 25.64 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 343 | 50 | T (Conductive Rubber) | |
MYR 21.36 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 392 | 50 | U (Urethane) | |
MYR 64.62 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 784 | 75 | C (Iron: FC20 Bright Chromate) | |
MYR 113.75 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 784 | 75 | M (MC Nylon) | |
MYR 42.19 | 1 Piece(s) | Available | 2 Day(s) or more | 10 | Swivel with Stopper | 588 | 75 | R (Synthetic Rubber) | |
MYR 66.76 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 588 | 75 | T (Conductive Rubber) | |
MYR 58.21 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 686 | 75 | U (Urethane) | |
MYR 73.17 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 588 | 100 | R (Synthetic Rubber) | |
MYR 81.17 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 490 | 100 | T (Conductive Rubber) | |
MYR 77.97 | 1 Piece(s) | Available | 2 Day(s) or more | - | Swivel with Stopper | 588 | 100 | U (Urethane) |
Loading...
Basic Information
| Type | Caster Body | Caster Mounting Type | Insert |
|---|
Specification/Dimensions
-
Caster Type_2
- Swivel
- Swivel with Stopper
-
Max. Load(N)
-
Wheel Dia. D(mm)
- 50
- 75
- 100
-
Wheel Material
- C (Iron: FC20 Bright Chromate)
- M (MC Nylon)
- N (Nylon)
- R (Synthetic Rubber)
- T (Conductive Rubber)
- U (Urethane)
-
type
- PHCHF100-R
- PHCHF100-T
- PHCHF100-U
- PHCHF50-C
- PHCHF50-M
- PHCHF50-N
- PHCHF50-R
- PHCHF50-T
- PHCHF50-U
- PHCHF75-C
- PHCHF75-M
- PHCHF75-N
- PHCHF75-R
- PHCHF75-T
- PHCHF75-U
- PHCHFS100-R
- PHCHFS100-T
- PHCHFS100-U
- PHCHFS50-C
- PHCHFS50-M
- PHCHFS50-N
- PHCHFS50-R
- PHCHFS50-T
- PHCHFS50-U
- PHCHFS75-C
- PHCHFS75-M
- PHCHFS75-R
- PHCHFS75-T
- PHCHFS75-U
-
CAD
- 2D
- 3D
Days to Ship
-
- All
- 2 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
