Aluminum Frame 5 Series/slot width 6/25x50mm

Aluminum Frame 5 Series/slot width 6/25x50mm
  • Volume Discount

MISUMI_Test

MISUMI_Test

(i)Caution

  • Items with L Length longer than 2,001mm will be treated as special delivery from 01/11/02019,
    and additional cost RM119.30 will be added in each product for the delivery fee.
    For items L Length shorter than 2,000mm will not have any price increase

PDFP.2-531-2014

Part Number

Configured Part Number is shown.

Note that, for some of the types shown here, order might be unable to be received by the MISUMI Indonesia offices.

Aluminum Extrusion 5 Series/slot width 6/25x50mm:Related Image

Specifications

Part Number - L
HFS5-2550 - 800
KHFS5-2550 - 4000
■Configurable Length Extrusions
Type [ M ]Material [ S ]Surface Treatment Part Number L 0.5mm Increment Mass
kg/m		 Sectional Area mm2 Cross Sectional Moment of Inertia mm4
ℓx ℓy
HFS A6N01SS－T5 Clear Anodize HFS5-2550 50~4000 1.36 503 2.97x104 12.74x104
HFS A6N01SS－T5 Black Anodize HFSB5-2550 50~4000 1.36 503 2.97x104 12.74x104
NFS AW-6063－T5 Clear Anodize NFS5-2550 50~4000 1.36 503 2.97x104 12.74x104
[ ! ]Applicable to 6000mm depending on products.
[ ! ]For some extrusions, MISUMI may be unable to accept the order.
Refer to Information of Special Orders (P.103) and contact the person in charge of Special Orders at MISUMI QCT Center.

■Fixed Length Extrusions (Effective Length 4000mm)
[ ! ]Part numbers beginning with the character "K" indicate Fixed Length Extrusion.
Type [ M ]Material [ S ]Surface Treatment Part Number L
mm		 Sectional Area mm2 Cross Sectional Moment of Inertia mm4
ℓx ℓy
HFS A6N01SS－T5 Clear Anodize KHFS5-2550 4000 503 2.97x104 12.74x104
HFS A6N01SS－T5 Black Anodize KHFSB5-2550 4000 503 2.97x104 12.74x104
NFS AW-6063－T5 Clear Anodize KNFS5-2550 4000 503 2.97x104 12.74x104
[ ! ]"Effective Length 4000mm" represents the extrusion with 4000mm or more effective length.
(several cm)

Alterations

Aluminum Extrusion 5 Series/slot width 6/25x50mm:Related Image
Alterations are available for Configurable Length Extrusions. >> Click here

Part Number

CAD Data download and 3D preview are not available because the part number has not yet been determined.

  • *In order to open the CAD Data download and 3D preview screen, the part number must be fixed.
  • Please confirm the part number from "Specification / Dimension"on the left side, and then perform the CAD Data Download / 3D Preview operation.
Loading...

CAD Download

30
45
60
  1. 1
Part Number
HFS5-2550-[50-1800/0.5]
HFS5-2550-[1801-4000/0.5]
HFSB5-2550-[50-1800/0.5]
HFSB5-2550-[1801-4000/0.5]
KHFS5-2550-4000
KHFSB5-2550-4000
KNFS5-2550-4000
Part NumberStandard Unit PriceMinimum order quantityVolume DiscountDays to ShipRoHSExtrusion Type_ Surface Treatment Material L Dimension Fixed, Specified Overall Length L (Effective Length)
(mm) 		Overall Length L
(mm)

-

1 Piece(s) 2 Day(s) or more 10HFS (Standard)Clear AnodizeA6N01SS-T5Configurable-50 ～ 1800

-

1 Piece(s) 2 Day(s) or more 10HFS (Standard)Clear AnodizeA6N01SS-T5Configurable-1801 ～ 4000

-

1 Piece(s) 2 Day(s) or more 10HFS (Standard)Black AnodizeA6N01SS-T5Configurable-50 ～ 1800

-

1 Piece(s) 2 Day(s) or more 10HFS (Standard)Black AnodizeA6N01SS-T5Configurable-1801 ～ 4000

MYR 261.36

1 Piece(s)Available 2 Day(s) or more 10HFS (Standard)Clear AnodizeA6N01SS-T5Stationary4000-

MYR 378.50

1 Piece(s)Available 2 Day(s) or more 10HFS (Standard)Black AnodizeA6N01SS-T5Stationary4000-

MYR 308.51

1 Piece(s)Available 2 Day(s) or more -NFS (Economy)Clear AnodizeA6063S-T5Stationary4000-

Loading...

  1. 1


Basic Information

Standard Extrusion Size(mm) 25 Extrusion Size 25x50 Extrusion Series 5 Series
Extrusion Type Rectangle Shape Number of Extrusion Slots 1 Slot x 2 Slots Number of Slotted Surfaces Four-Side Slots
Surface Milled Not Provided Extrusion Size: Width (A)(mm) 25 Extrusion Size: Thickness (T)(mm) 50
