Cable Clamp with Urethane to Save Space
Click this image to zoom it.
Move the mouse over the image to zoom
- Volume Discount
Space-saving compatible parts which are 20 mm thick
- Space-saving
- Steel
- Powder-Coated
● This is the improved product of the cable clamp with urethane.
● The ledge at the top has been cut as much as possible to save the space.
● The corner has been rounded for greater safety.
● The specification of the mounting hole is the same as before the improvement.
· It does not have a waterproof and dustproof structure.
· We recommend indoor use.
· Since the mounting threaded hole is painted after threading, it will be shipped with the paint on the threads.
■ Body
| Material | SPHC |
| Plate Thickness | 1.6 mm |
■ Flexible Urethane Foam
| Apparent Density | 45.8 kg/m3 | 75% Compression Residual Strain | 7.7% |
| 40% Hardness | 533.1N | Heatproof Temperature | 70°C or less |
| Tensile Strength | 248.7 kPa | Conductivity | Not Included |
| Stretch | 95% | Color | Gray |
| Tear Strength | 8.9 N/cm |
■ Surface Finish
| KSK | Powder Coating: Munsell Value 2.5Y9/1 Equivalent |
| KSG | Powder Coating: Munsell Value 5Y7/1 Equivalent |
| KSE | Powder Coating: Munsell Value 5Y8/1 Equivalent |
Part Number
Configured Part Number is shown.
Specifications
| Model Number | Weight (g) | ||
| Cream (2.5Y9/1) | Gray (5Y7/1) | 5Y8/1 | |
| KSK-60 | KSG-60 | KSE-60 | 146 |
| KSK-100 | KSG-100 | KSE-100 | 197 |
| KSK-150 | KSG-150 | KSE-150 | 261 |
| KSK-220 | KSG-220 | KSE-220 | 347 |
More Information
| Part Number |
|---|
| KSG-60 |
| KSK-60 |
| KSK-100 |
| KSK-150 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Dimension width (mm) | Color |
|---|---|---|---|---|---|---|
MYR 96.21 | 1 Piece(s) | Available | 1 Day(s) | 100 | Gray (Approximately Munsell Value 5Y7/1) | |
MYR 96.21 | 1 Piece(s) | Available | 1 Day(s) | 100 | Cream (Munsell 2.5Y9/1) | |
MYR 126.43 | 1 Piece(s) | Available | 1 Day(s) | 140 | Cream (Munsell 2.5Y9/1) | |
MYR 144.20 | 1 Piece(s) | Available | 1 Day(s) | 190 | Cream (Munsell 2.5Y9/1) |
Loading...
Basic Information
| Material | Iron | Main body plate thickness(mm) | 1.6 | Dimension vertical(mm) | 70 |
|---|---|---|---|---|---|
| Dimension thickness / depth(mm) | 21.6 | Paint - surface treatment | Powder Paint | Screw size | M4 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
