Global Harness Series Yaskawa Electric ΣV for Encoder
- Volume Discount
All-time-low price in series Sino-Japanese identical model sold
- Robot
- AC Servo
- Encoder
● A common model number has been adopted for Japan and China.
● We support local supply for customers
who are expanding into global business.
● The least expensive product in this series.
The connector used is a Misumi original.
Part Number
Configured Part Number is shown.
SVEYF-SGFV1-D-10
Specifications
| Compatible Amplifier | Compatible Motor | Outline Image | Model Number | Cable Type | Specified Length (m) |
| ΣV | SGMJV-A5A,01A 08A SGMAV-A5A, 08A, 01A and C2A SGMPS-01A ~ 04A | (1) For Direct Connection | SVEYF-SGFV1 | D (For Low Speed Movable) | 3 5 10 |
More Information
| Outline Image Drawing | (1)  Amplifier Side Motor Side |
| Specified Length (m) | ~ 1 | 2 ~ 10 |
| Tolerance | +10mm | +50mm |
Cable Flexibility Test Data
| Conditions | 1. Rotation Speed: 10 r/min 2. Average Measurement Distance: 1.8 m 3. Flexibility Radius: R = 125 mm |
| Remarks | Crawler cable curve tester used (LC859) Elastic cable material applied |
| Measurement Standard | Bend count of 5 million times or more when cable tore completely and stopped |
| Result | Tester stopped if cable was not torn by 5 million bend counts |
Basic Information
| Supported equipment | Servo | Length(m) | 10 | Application 1 | For Encoder |
|---|---|---|---|---|---|
| Connector shape | Straight | Outer diameter image | Double-ended | Cable type | Low Speed Mobile |
| Shield | N/A | Supported amplifiers | ∑V | Supported motors | ( SGMJV-5A, 01A, SGMAV-A5A, 01A, C2A, SGMPS-01A ) |
Specification/Dimensions
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
