Tensile Spring
The tensile string is second most-used following the compression coil and has hooks on both ends.
Japanese Only
Part Number
Configured Part Number is shown.
| Part Number |
|---|
| 22-0422 |
| 22-1021 |
| 22-1034 |
| 22-1420 |
| 22-1421 |
| 22-B132 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Max. Load (Secified Range) (N) | Max. Load (N) | Free length (mm) | O.D. (Ø) | Initial Tension (N) | Spring Constant (N/mm) | Wire diameter (Ø) | Maximum Elongation (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
MYR 14.53 | 1 Piece(s) | 2 Day(s) or more | 1.26~3.50 | 1.57 | 25 | 4 | 0.098 | 0.023 | 0.3 | 66 | ||
MYR 35.90 | 1 Piece(s) | 1 Day(s) | 15.01~30.00 | 15.9 | 40 | 10 | 1.72 | 0.304 | 0.9 | 47.2 | ||
MYR 43.77 | 1 Piece(s) | 1 Day(s) | 15.01~30.00 | 21.8 | 80 | 10 | 2.68 | 0.188 | 1 | 100 | ||
MYR 47.14 | 1 Piece(s) | 2 Day(s) or more | 15.01~30.00 | 26 | 50 | 14 | 3.32 | 0.413 | 1.2 | 55.4 | ||
MYR 55.00 | 1 Piece(s) | 2 Day(s) or more | 15.01~30.00 | 26 | 65 | 14 | 3.32 | 0.261 | 1.2 | 86.8 | ||
MYR 14.53 | 1 Piece(s) | 3 Day(s) or more | ~1.25 | 1.14 | 13 | 1.8 | 0.135 | 0.069 | 0.2 | 14.4 |
Loading...
Basic Information
| Material | SUS304-WPB | Type | Standard Type | Hook Opposing Angle | 180° (Standard) |
|---|
Specification/Dimensions
-
Max. Load (Secified Range)(N)
- ~1.25
- 1.26~3.50
- 15.01~30.00
-
Max. Load(N)
-
Free length(mm)
-
O.D.(Ø)
-
Initial Tension(N)
-
Spring Constant(N/mm)
-
Wire diameter(Ø)
-
Maximum Elongation(mm)
-
type
- 22-0
- 22-B
-
CAD
- 3D
Days to Ship
-
- All
- 1 Day(s) or Less
- 2 Day(s) or Less
- 3 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
Additional Products in this Category
- Tension Springs/Configurable Length
- Hook Insertion for Springs
- Extra Light Load/Light Load/Light to Medium Load/Medium Load
- UltraSpring Tension Coil Springs
- D Series Tensile Coil Spring (DIN 2098 Standard)
- K Series Tensile Coil Spring (Japan Spring Manufactures Association Standard)
- Round-Wire Tensile Coil Spring J Spring JB
- Adjustable Tensile Coil Spring
