ECO Cable (for Microphone Cords), EM-MEES Series
[Features]
· The jacket does not contain any harmful materials such as halogens or lead. As such no hazardous substances will be released, even if disposed of through incineration or via landfill.
· The jacket materials, other than the conductor, are all of the same type, helping to make recycling easier.
• The jacket uses highly flexible material for easy processing. In addition, it is thinner and lighter than conventional MVVS, resulting in even higher workability.
• Little in the way of fumes are emitted when compared to conventional MVVS, while still maintaining equivalent levels of flame retardancy.
Japanese Only
Part Number
Configured Part Number is shown.
EM-MEES-3X0.75SQ-81
| Part Number |
|---|
| EM-MEES-3X0.75SQ-81 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship |
|---|---|---|---|---|
MYR 1,377.11 | 1 Piece(s) | 3 Day(s) or more |
Loading...
Basic Information
| Overall Length(m) | 81 | Conductor Cross Section(mm2) | 0.75 | AWG size(AWG) | 18 |
|---|---|---|---|---|---|
| Number Of Cores(Core) | 3 | Finished outer diameter(mm) | 6.4 | Rated Voltage | 60V |
| Shield | Available | Sheath (outer coating) color | Gray | Grounding Wire | NA |
| Sheath (outer coating) material | Polyethylene-Based | Insulation body materials | Polyethylene-Based | Number of strands/diameter of strands(Number of units/mm) | 30/0.18 |
| Insulation body outer diameter(mm) | 1.9 | Other Properties | Flame Retardant | Other standards | JCS |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
