4.80 mm Pitch Minifit Relay Terminal (5005)

[Features]
• Molex terminals are completely protected by the housing's insulation wall (compatible housing: 5025 receptacle).

Part Number

Configured Part Number is shown.

5005TL

Part Number
5005TL

Part Number	Standard Unit Price	Minimum order quantity	Volume Discount	Days to Ship
	MYR 1.30	1 Piece(s)		1 Day(s)

Applicable pin/contact	Female (socket)	Wire connection method	Crimp	Application	Cable Connection
Conforming housing	5025	Applicable size AWG	18–24	Terminal shape	Individual
Mating Partner	5006	Applicable wire coating outer diameter(mm)	3.0

Please check the type/dimensions/specifications of the part 5005TL in the 4.80 mm Pitch Minifit Relay Terminal (5005) series.

Configure

1 Part Numbers

Configure Remaining Specifications

Completed

The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
